Image |
N/A
 |
Model |
N/A FL38CBL58-2450 |
Product Type |
N/A DC Motor |
Series |
N/A Brushless (BLDC) Motor with Planetary Gearbox |
Number of Poles |
N/A 4 |
Number of Phase |
N/A 3 |
Direct Current (DC) Rated Voltage |
N/A 24 V |
Rated Voltage |
N/A 24 V |
Rated Torque |
N/A 70 mN·m2 N·m |
Rated Speed |
N/A 4000 rpm |
Rated Torque |
N/A 70 mN·m2 N·m |
No Load Speed |
N/A 5000 rpm |
Length (L) |
N/A 38.4 mm |
Rated Power |
N/A 30 W |
Peak Torque |
N/A 210 mN·m |
Line to Line Resistance |
N/A 2 ohms |
Line to Line Inductance |
N/A 1.5 mH |
Peak Current |
N/A 5.1 A |
